KiCad PCB Design Services in Chicago
Schematic capture, PCB layout, DFM reviews and manufacturing files — fast, reliable, US-based.
Services & Pricing
Service Package
Prototype Package
Schematic capture up to 50 components
2 to 4-layer PCB layout up to 100mm x 100mm
Gerbers, BOM, Pick-and-Place
Service Package
Production Package
Multi-layer layout up to 18 layers
High-speed routing (DDR, USB, Ethernet, etc)
DFM/DFT review and stack-up guidance
Deliverables: Gerbers, ODB++, IPC-356, BOM, CPL
Capabilities
01
Schematic & Libraries
KiCad schematic capture, custom symbol/footprint library creation, ERC checks and design documentation.
02
PCB Layout
2-16 layer boards, controlled impedance, high-speed routing, differential pairs, DDR, USB, Ethernet.
03
Manufacturing
Gerbers/ODB++, IPC-356 netlist, BOM, pick-and-place, fab drawings, DFM/DFT review and CAM checks.
